Compact TLC-MS Complete System

Specification Compact Mass Spectrometer Ion Source : ESI, APCI or APCI/ASAP; Polarity : Positive & negative ion switching in single analysis; Flow Rate Range ESI: 10 μL/min to 1 mL/min, APCI: 10 μL/min to 2 mL/min; m/z Range : m/z 10 to 2,000; Acquisition Speed : 10,000 m/z units/sec; Sensitivity (ESI) : 10 pg reserpine (FIA - 5 μL injection at 100 μL/min) 100:1 S/N (RMS) with SIM of m/z 609.3.; Accuracy : +/- 0.1 m/z units of the entire acquisition range; Stability : +/- 0.1 m/z units over 12 hour period (65 °F - 75 °F), (18 °C - 24 °C) operating temperature); Polarity Switching Speed : 50 ms; Dynamic Range : 4-5 orders of magnitude; Gas Supply : 60 psi, >98% pure Nitrogen; Gas Consumption : < 10 L/min; Solvents : LC/MS-grade solvents; Weight : Max 35 kg; Dimension : Max 70 x 30 x 60 cm; Line Voltage : 100 - 240 VAC; Line Frequency : 47 - 63 HZ; Power Consumption : 915 VA (including PC); All critical and commonly used components are located on the front of the instrument for easy access. Pump and source exhaust are bi-directional (left or right hand) to allow for optimal hood or bench location Solvent-resistant exterior package; ASAP® (Atmospheric Solids Analysis Probe) permits chemists affordable and reliable sample analysis of solid and liquid samples such as reaction mixtures, food samples, natural products and tablets without chromatography or additional sample preparation. Touch Express Open Port Sampling Interface (OPSI) designed for simple sampling of solids, liquids and sample preparation tips and fibers Plate ExpressTM is a device that provides a simple, automated means of obtaining mass spectra directly from TLC plates, creating a technique known as TLC/MS, Combined with Advion’s expression®, compact mass spectrometer (CMS) this becomes, TLC/CMS, Using this technique chemists can quickly and confidently identify products even in complex mixtures without additional sample preparation; ESI Calibration/tune standard mix, APCI Calibration/tune standard mix LC connection kit plus all other standard CMS parts, SWL_QUANTEXPRESS_1 Data processing software for quantitation of data acquired through Mass Express Replacement API Heated Capillary
